Temporary Grandstand Portable Outdoor Bleachers With Galvanized Steel Floor

Basic Information
Place of Origin: China
Model Number: ARH-F1715
Minimum Order Quantity: 100PCS
Packaging Details: PP woven bag, air bubble film
Delivery Time: 30 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 5000PCS per month
Detail Information
Material: Glavanized Steel Color: Blue/Orange/Green/Yellow,Customized; Black; Red; Blue;
Size: Optional Feature: Portable
Support: Metal Frame Packing: Air Bubble Film
High Light:

Temporary Grandstand Portable Outdoor Bleachers


Galvanized Steel Portable Outdoor Bleachers


Screw Fixing Portable Outdoor Bleachers

Product Description

Portable Outdoor Bleachers Temporary Grandstand With Galvanized Steel Floor
Product name: Steel structure outdoor bleacher
Product material: Q235 national standard iron profile
The number of layers can be made: 10 layers-20 layers / can be customized
Structure composition: pedals, plastic seats/aluminum alloy plate seats, guardrails, stand brackets, stairs, step flooring
Seat style: aluminum alloy seat plate or HDPE/PP plastic seat
Pedal style: fireproof board, non-slip iron checkered board, aluminum alloy board
Base height: Conventional 1m/2m/no base height, can be customized
Maximum load: 250kg/seat
Fixing method: screw fixing
Packaging method: Bubble film packaging
Features of portable outdoor bleacher
Outdoor bleacher Seat
1. The chair surface adopts hollow blow molding manufacturing process, and selects polyethylene material (HDPE) for one-time processing and molding. The seat surface has rounded edges and corners, the molecular weight is relatively concentrated, and the joints are well bonded.
Polyethylene (HDPE) is a milky white translucent waxy solid with a molecular weight of 100,000 to 300,000. The homopolymer density is generally 0.955~0.965, linear structure, few branches, crystallinity is 80%~90%. The degree of branching of HDPE, the molecules can be packed tightly, so the density (0.941g/cm3~0.965g/cm3) and high crystallinity.
2. Seat surface dimensions: seat width×seat depth×seat back height=400*360*85 (㎜), the overall service life is ≥10 years.
Accessories of outdoor bleacher seat
1. The seat can be directly installed on the stands.
2. All steel components are electrostatically sprayed on the automatic spraying line after rust removal.
3. Fasteners: The seat is connected with the concrete on the ground of the stand with novel expansion bolts, and the connection is firm and not loose.
4. The design, selection and installation of the seat are in line with the design of the gymnasium, beautiful and comfortable, easy to install, maintain and manage.
5. Seat name: hollow blow molding seat;
6. The color of the seat group: determined by the owner according to the provided plan;
7. Seat wall thickness: not less than 3mm;
8. Seat installation method: directly installed on the steps, the seat installation pitch is 480mm;


Product Outdoor bleacher
Material Chair: HDPE chair
Structure Frame: Cold roll steel dealt with powder coating or galvanization
Flooring: galvanized steel sheet Or alumium floor
Safety Railing: Steel with powder coating or Stainless steel is optional
Chair Type Bench, Bucket chair, Foldable chair
Installation Type Floore mounted type or Rise mounted type
Color of Steel Structure Black or Grey
Railings Safety Railing on two sides of the bleacher, backside railing is optional
Step Height 260-300mm
Step Width 700-900mm
Stair Step Width 800-1000mm
Packing PP woven bag, Carton, Air bubble film
MOQ 100 seats per set
Delivery Time 25-30 days according to the quantity

Stadium, Race court,court for event


It is produced in strict accordance with the drawings of the design department. The material is cut by an aluminum cutting machine, and the imported aluminum electrode is used to complete the welding process through an argon arc welding machine, followed by grinding, cleaning, inspection, packaging and leaving the factory.
The stand is equipped with casters on the basis of various simple stands to make the movement of the simple stands more convenient. The tube stand is simple in structure, easy to install and transport: after use, just erect the stand and push the non-scratch universal wheel that matches the stand itself to easily move the stand to the installation storage space: beautiful appearance, low cost: layer The number is controlled within 4 floors, 1 meter high, without guardrails, and the length of the stands is controlled within 4.5 meters. The size can be designed according to customer requirements.
The folding stand system has undergone rigorous and precise calculations and tests. All metal parts have been hot-dip galvanized. They have strong toughness, shock resistance, wind resistance, high temperature, low temperature, humidity, acid and alkali resistance, and are suitable for Harsh use environment. You only need to provide your size (usually length, width and height dimensions) and modeling requirements, or hand-drawn sketches to us, our professional designers will according to your specific situation, between the use effect and cost budget We will provide you with a satisfactory solution, and use the three-dimensional software to show you the effect. You can find and solve the problem by referring to it, so that you can buy it without any worries.
The temporary grandstand can be built up to 30 floors with a height of 11 meters, and all metal components are galvanized to prevent rust. Features: less structure, easy to build and disassemble, the basic structure and special parts of all standard modular single module structure, each weight is not more than 25KG, two workers can easily install. The joint structure is reasonable, easy to operate, light and simple. Large bearing capacity, high structural strength, overall stability, safety and reliability. Adopt wedge insertion self-locking mechanism. The plug-in has self-locking function, which can be locked by pressing the latch or unplugged for disassembly. The components are standardized to facilitate transportation and management.
Temporary Grandstand Portable Outdoor Bleachers With Galvanized Steel Floor 0
Temporary Grandstand Portable Outdoor Bleachers With Galvanized Steel Floor 1
Temporary Grandstand Portable Outdoor Bleachers With Galvanized Steel Floor 2
Why Choose Us?
Honest merchants: We insist on strict control of product quality, rely on quality to expand the market, and encourage technological innovation.
Quality Assurance: Over the years, we have been trusted by customers with stable products, timely delivery, and excellent after-sales service. We have a broad market and a good reputation.
Price commitment: In order to ensure the reliability of the product, all materials selected are high-quality steel. Under the same competitive conditions, on the basis of not reducing the technical performance of the product, we will sincerely provide it at a preferential price.
1.Can you do OEM?
Yes, we do OEM according to clients’ requirements.
2.What’s your lead time?
It’s according to the quanity. Usually 25-30 days based on MOQ quantity.
2.Can you provide samples?
Yes, we could provide samples with the sample charge, but it will be refund if you place the mass production order.
4.What’s your delivery port?
From Chongqing, Shanghai, Guangzhou or Shenzhen
5.What’s your payment terms?
TT transfer is preferred.
6.Do you have color choice?
Yes, we have multi colors for the clients.
